DJI O4 Air Unit

Myndavél
Sensor:
1/2-inch CMOS Sensor

FOV: 117.6°
The equivalent focal length: 14 mm
Aperture: f/2.8
Focus: 0.6 m to ∞

Video: MP4
Max Bitrate: 100 Mbps
Colore mode: Normal mode

ISO:
100-6400 (Auto)
100-12800 (Manual)

EIS:
RockSteady 3.0+
Stabilization function off (supports Gyroflow)
When RockSteady is enabled, the shooting angle only supports standard.

Video Resolution:
4K(4:3): 3840 x 2880@30/50/60fps
4K(16:9): 3840 x 2160@30/50/60fps
1080P(4:3): 1440 x 1080@30/50/60/100/120fps
1080P(16:9): 1920 x 1080@30/50/60/100/120fps

Innbyggt minni: 23GB

Styður MicroSD: NO

Stærð
Þyngd:
Air Unit (camera module excluded): Approx. 5.1 g
Air Unit (camera module included)：Approx. 8.2 g*
Antenna: Approx. 0.75 g
*The lens mount is not included. With the lens mount, the weight is 9.2 grams.

Lengdir:
Transmission Module: 30×30× 6 mm (L×W×H)
Camera Module: 13.44×12.36×16.50 mm (L×W×H)
Coaxial Cable: 50 mm
3-in-1 Cable: 50 mm
Antenna: 80 mm


Video Transmission
Lowest Latency:
With DJI Goggles 3 and pick racing mode:
With 1080p/100fps video transmission quality, the latency is as low as 20 ms.
With DJI Goggles N3 and pick racing mode:
With 1080p/100fps video transmission quality, the latency is as low as 24 ms.
With DJI Goggles 2 or Goggles Integra：
With 1080p/100fps video transmission quality, the video transmission latency is less than 35 ms.

Max Video Transmission Range:
With DJI Goggles 3/DJI Goggles N3:
10 km (FCC),6 km (CE),6 km (SRRC)

Input voltage:
3.7 - 13.2V


Í Kassanum:

DJI O4 Air Unit Camera Module × 1

DJI O4 Air Unit Transmission Module × 1

DJI O4 Air Unit Antenna × 1

DJI O4 Air Unit 3-in-1 Cable × 1

DJI Goggles 3 + DJI FPV Remote Controller 3
DJI Goggles N3 + DJI FPV Controller 3
DJI Goggles 2 / DJI Goggles Integra + DJI FPV Remote Controller 2
